NAD T743 AV Surround Sound Receiver

The NAD T743 is a high-performance AV surround receiver designed to combine NAD's renowned musical stereo performance with immersive home cinema capabilities. Featuring high-current amplification, Dolby Digital and DTS decoding, and extensive connectivity, the T743 is equally at home powering a music system or a multichannel home theater.

### Specifications

- Model: NAD T743
- Type: 5.1 Channel AV Surround Receiver
- Power Output:
- 50 W per channel into 8 Ω (5 channels driven)
- Dynamic Power:
- 70 W into 8 Ω
- 100 W into 4 Ω
- 140 W into 2 Ω
- Frequency Response: 20 Hz – 20 kHz (±0.3 dB)
- Total Harmonic Distortion (THD): 0.08%
- Signal-to-Noise Ratio:
- Line: >95 dB
- Surround Formats:
- Dolby Digital
- Dolby Pro Logic II
- DTS
- DTS Neo:6
- EARS Surround
- Inputs:
- Multiple Analog Audio Inputs
- Front AV Input
- Optical Digital Inputs
- Coaxial Digital Inputs
- Composite Video
- S-Video
- AM/FM Tuner with RDS
- Outputs:
- 5 Speaker Outputs
- Active Subwoofer Pre-Out
- Headphone Output (6.3 mm)
- Composite Video
- S-Video
- Features:
- High Current PowerDrive amplification
- AM/FM RDS tuner
- Bass management
- Adjustable speaker levels and delays
- Front-panel AV inputs
- Tone controls with Tone Defeat
- Programmable remote compatible
- Dimensions (W × H × D): 435 × 150 × 350 mm
- Weight: Approx. 11.5 kg
- Power Supply: 230 V AC

### Condition

- Tested and in good working order.
- Cosmetic condition is consistent with age, with visible signs of normal use.
